S355J2G3 Carbon Steel Forgings S355J2 , Pressure vesel Forged Steel Ring

S355J2G3 Carbon Steel Forgings S355J2 , Pressure vesel Forged Steel Ring

    • S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring
    • S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring
    • S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring
  • S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring

    Product Details:

    Place of Origin: China
    Brand Name: FY
    Certification: PED Certificates,ABS,BV,DNV,RINA,GL,LR,NK,KR,CCS
    Model Number: FY-0133

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC
    Price: Negotiation
    Packaging Details: sea worthy packing like wooden case,iron pallet or as customer's order.
    Supply Ability: 6000 Tons Per Month
    Contact Now
    Detailed Product Description
    Material: Carbon Steel Dimensions: Max OD Is 5000mm,
    Weight: 50Kg-14000Kg Heat Treatment: Normalizing Or Q+T
    Machining: Rough Machining Application: Mechanical Manufacture,Pressure Vesel

    S355J2G3 Carbon Steel Forged Ring S355J2 Hot Rolled Ring Hot Rolled Sleeve Forged Cylinder



    (1) Short Introduce:

    Max length:3000mm
    Max weight:15000kg
    Heat treatment: N,N+T,Q+T or as customer's requirement
    Report:3.1 Certificates,UT report,Material report or others.



    (2) Chemical Element:

    C≤ Si≤ Mn≤ P≤ S≤
    0.20% 0.55% 1.6% 0.035% 0.035%



    (3) Mechanical Properties:

    Tensile Strength(Mpa) 450~630
    Yield Stenght(Mpa) ≥265
    Impact (-20℃) 27J



    (4) Products process:

    The forgings manufacturing and inspecting process are showed in the following picture :



    S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring



    (5) Certfiticates List:

    Certificates list of Jiangyin Fangyuan
    ISO9001:2008 ISO14001:2004 PED Certificate
    ABS Certficate BV Certficate DNV Certificate
    RINA  Certficate GL  Certficate LR  Certficate
    CCS  Certficate NK  Certficate KR  Certficate
    API-6A  Certficate API-17D  Certficate CNAS  Certficate




    (6) The main manufacturing equipments:

    Name&Description

    Capacity

    Quantity

    3600Thydraulic press

    Max. single forging in 18T

    1

    2000T hydraulic press

    Max. single forging in 9T

    2

    800 hydraulic press

    Max. single forging in 5T

    1

    6T electrical hydraulic hammer

    Max.single forging in 5T

    1

    3T electrical hydraulic hammer

    Max.single forging in3T

    1

    Air hammer

    Max.single forging from250kg to 1000kg

    7

    Forging operation machine

    Max.singe forging from20T-5T

    7

    Heat treatment Furance

    Max.8000*5000*1500mm

    11

    CNC driling machine

    Max.5000mm

    2

    Vertical lathe

    From 1600 to 5000mm

    60

    Horizontal lathe

    Max.5000mm

    70

    Band sawing machine

    260-1300mm

    36



    S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring

    S355J2G3 Carbon Steel Forgings  S355J2 , Pressure vesel Forged Steel Ring



    (7)The main testing machine list:



    Item

     Name



    Model



    Precision



    Quantity



    Calibration cycle



    Remarks

    1



    UT fault detector

    CUD2080



    4



    1year



    2



    UT fault detector

    PXUT-U1



    1



    1year



    3



    UT fault detector

    PXUT-U350+



    1

    1year



    4



    Yoke flaw detector

    DA-400S



    1

    1year



    5



    UT fault detector

    USM 35X



    2

    1year



    6



    UT fault detector

    USN 60



    1

    1year



    7



    Reading directly spectrographer

    SPECTROTEST

    TXCO2

    B Class

    3

    1year



    8

    Reading directly spectrographer

    GS 1000

    A Class

    1

    1year



    9



    HB tester

    HB-3000B

    ±2.5%

    1

    1year



    10



    Leeb hardness tester

    TH140

    ±12HLD

    4

    1year



    11



    Leeb hardness tester

    EQUOTIP3

    ±12HLD

    1

    1year



    12



    Digisplay Rockwell hardness tester

    HRS-150

    ±1.5HRC

    1

    1year



    13



    Portable HB tester



    ±3.0%

    1

    1year



    14

    Automatic end quenching test machine

    WDZ-02



    1





    15



    Metallurgical Micaroscopy

    XJP-6A



    1

    1year



    16



    Chemical analysis equipment





    1Set

    1year





    (8) Company Introduction:

    Jiangyin Fangyuan Ringlike Forging Flange Co.Ltd was established in 1993.It’s the member of the Confederation of Chinese Metalforming Industry, Chinese wind energy association, China petroleum & Petro-chemical Equipment Industry Association.

    As the leading forging manufacturer in China, our company is specialized in manufacturing forged rings, forged discs, forged shaft ,flanges,valve forging and pressure vessel forgings. We could  provide you good quality forgings with competitive pirces.

    The company covers a total area of 100,000 m2 (square meters), building area of 70,000 m2(square meters). There are 600 staffes in the company. Among them, there are 138 senior engineers and technicians. We also have our own testing center lab. which is able to do chemical analysis, metalloscope test, spectrometer test, mechanical property test and Ut test.

    The company has been proved by ISO9001,ISO14001, TUV, API,LRS, GL,BV, ABS,DNV, CCS ,RINA,KR and NK. For more information ,you can contact me freely.

    The GE,SKF ,ABB and Siemens are our main forgein customers now.I hope that my company could have the opportunity to established a long-term cooperative relationship with you.I hope to receive your inqury soon.
