SA182-F51 S31803 Duplex Stainless Steel Ball Valve Forging Ball Cover Forgings Blanks

SA182-F51 S31803 Duplex Stainless Steel Ball Valve Forging Ball Cover Forgings Blanks

  • SA182-F51 S31803 Duplex Stainless Steel Ball Valve Forging Ball Cover Forgings Blanks
SA182-F51 S31803 Duplex Stainless Steel Ball Valve Forging Ball Cover Forgings Blanks
Product Details:
Place of Origin: Jiangsu,China
Brand Name: FY
Certification: PED 3.1 Certificates,ABS,BV,DNV,RINA,GL,LR,NK,KR,CCS
Model Number: FY-0014
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: sea worthy packing like wooden case,iron pallet or as customer's order.
Delivery Time: 18-30 days
Supply Ability: 3000 Tons Per Month
Contact Now
Detailed Product Description
MaterialAlloy Steel 42CrMo4: F51 Dimensions: Max OD Is 5000mm,
Weight: 10Kg-10000Kg Heat Treatment: Solution
Machining: Rough Machining Or Finish Maching Application: Ball Valve
Standard: ASME / ASTM
High Light:

forged valve body

,

custom forgings

SA182-F51 Duplex Stainless  Steel Ball Valve Forging Ball Cover Forgings Blanks  Rough Machined


(1) Material Stardard:

ASTM/ASME-2013 SA182-F51


(2) Element(%):

F51

UNS

S31803

C≤

0.030



Mn≤

2.00



P≤

0.030

S≤

0.020

Si≤
1.00

Ni

4.5~6.5

Cr

21.0~23.0

Mo

2.50~3.50


(3) Heat Treatment:

Solution



(4) Mechinical Properties:

Item Tensile Strength Yield Strength Elongation Rate Reduction Of Area Hardness
F51 620 Mpa 450 Mpa 25% 45% ...



(5) Company Certfiticates List:

Certificates list of Jiangyin Fangyuan
ISO9001:2008 ISO14001:2004 PED Certificate
ABS Certficate BV Certficate DNV Certificate
RINA  Certficate GL  Certficate LR  Certficate
CCS  Certficate NK  Certficate KR  Certficate
API-6A  Certficate API-17D  Certficate CNAS  Certficate


(6) Company Introduction:
Jiangyin Fangyuan Ringlike Forging Flange Co.Ltd was established in 1993.It’s the member of the Confederation of Chinese Metalforming Industry, Chinese wind energy association, China petroleum & Petro-chemical Equipment Industry Association.

As the leading forging manufacturer in China, our company is specialized in manufacturing forged rings, forged discs, forged shaft ,flanges,valve forging and pressure vessel forgings.

The company covers a total area of 100,000 m2 (square meters), building area of 70,000 m2(square meters). There are 600 staffes in the company. Among them, there are 138 senior engineers and technicians. We also have our own testing center lab. which is able to do chemical analysis, metalloscope test, spectrometer test, mechanical property test and Ut test.
The company has been proved by ISO9001,ISO14001, TUV, API,LRS, GL,BV, ABS,DNV, CCS ,RINA,KR and NK.

The GE,SKF ,ABB and Siemens are our main forgein customers now.I hope that my company could have the opportunity to established a long-term cooperative relationship with you.I hope to receive your inqury soon.
